Specification

Description

Number of Class 3 Server Connections

5

Supported PLC Types

PLC2, PLC5, SLC, CLX, CMPLX, MICROLX

Supported Message Types

PCCC and CIP

Class 3 Client Connections

Connected: 2
Unconnected: 1

Number of Class 1 I/O Connections

8

I/O connection sizes

248/248

Max RPI time

5 ms per connection

CIP Services Supported

0x4C - CIP Data Table Read
0x4D - CIP Data Table Write
CIP Generic

Command List

Support for 100 commands per Client, each configurable for command type, IP address, register to/from addressing and word/bit count.

Command Sets

PLC-2/PLC-3/PLC5 Basic Command Set
PLC5 Binary Command Set
PLC5 ASCII Command Set
SLC500 Command Set

Specification

Description

Command List

Up to 100 commands per Master port, each fully configurable for Function Code, slave address, register to/from addressing and word/bit count.

Supported Modbus Function Codes

1: Read Coil Status
2: Read Input Status
3: Read Holding Registers
4: Read Input Registers
5: Force (Write) Single Coil
6: Preset (Write) Single Holding Register

15: Force (Write) Multiple Coils
16: Preset (Write) Multiple Holding Registers
22: Mask Write Holding Register (Slave Only)
23: Read/Write Holding Registers (Slave Only)

Software configurable communication parameters

Baud rate: 110 baud to 115.2 kbps
Parity: None, Even, Odd
Data Size: 7 or 8 bits
Stop bits: 1 or 2
RTS on/off delay: 0 to 65535 milliseconds
Modbus RTU mode (binary) with CRC-16
Modbus ASCII mode with LRC error checking
Floating Point Data Floating point data movement supported, including configurable support for Enron and Daniel implementations

Polling of Command List

Configurable polling of command list, including continuous and on change of data, and dynamically user or automatic enabled.

Status Data

Error codes available on an individual command basis. In addition, a slave status list is maintained

Node Address

1 to 247 (software selectable)

RS Interface

RS232, RS422, and RS485

Transmit and Receive Buffer Size

255 byte Transmit character length with 0 to 65535 millisecond delay between each transmitted character

Specification

Description

Power Supply

24 Vdc nominal
10Vdc to 36 Vdc allowed
Positive, Negative, GND Terminals

Current Load

24 Vdc nominal @ 300mA
10 to 36 Vdc @ 610mA maximum

Operating Temperature

-25°C to 70°C (-13°F to 158°F )

Storage Temperature

-40°C to 80°C (-40°F to 176°F )

Relative Humidity

5% to 95% RH with no condensation

Shock

IEC 60068-2-27; 15G @ 11ms, 3-Axis (Operational)
IEC 60068-2-27; 30G @ 18ms, 3-Axis (Non-Operational)

Vibration

IEC 60068-2-6; 5G @ 10Hz to 150Hz

Dimensions
(Height x Width x Depth)

Standard: 5.38 in x 1.99 in x 4.38 in
(13.67 cm x 5.05 cm x 11.13 cm)

LED Indicators

Configuration (CFG) and Error (ERR) Communication Status
Power (PWR) and Hardware Fault (FLT)
Network Status (NS) EtherNet/IP Class I or Class III Connection Status
Module Status (MS) Module Configuration Status
Ethernet Communication Port Link/Activity and 100mbit
Serial Communication Port Receive (RX) and Transmit (TX)

Ethernet Port

10/100 Base-T half-duplex RJ45 Connector Electrical Isolation 1500 Vrms at 50 Hz to 60 Hz for 60 seconds, applied as specified in section 5.3.2 of IEC 60950: 1991 Ethernet Broadcast Storm Resiliency = less than or equal to 5000 [ARP] frames-per-second and less than or equal to 5 minutes duration

Serial Ports

4

Serial Port Isolation

2500 Vrms port signal isolation per UL 1577 serial port communication signal uses RF(Radio Frequency) modulation signal as isolation media, IC chip model is SiliconLabs Si844x(Si8440,Si8441,Si8442).

Shipped With Each Unit

2.5 mm screwdriver, J180 Power Connector,
(1 to 4) RJ45-DB9M Serial Adapter Cable (serial protocol),
(1 to 4) DB9 to Screw Terminal Adapter (serial protocol)
